File Requirements

Files Requested for PCBA

In order to insure that you receive PCBs that meet your needs and expectations the following is a list of the files that we need to process your order efficiently and correctly.  Please review your files to insure that what you have submitted to be built is truly representative of your design files.

Contact Us
PCB Manufacturing

Required Information for PCB Assembly

BOM (Bill Of Materials)

BOM is a list of parts used in manufacturing the end products. It shows what parts are needed to assemble the boards, and where these parts should be placed and assembled. We accept the BOM in the format of .xls, xlsx or .csv. The BOM for Turn-key and Partial Turn-key orders may request a few more information than the BOM for consigned/kitted orders. Here is the Detail.

BOM for consigned/kitted orders may include following information:

Line#

Quantity Per Part Number

Reference Designator

Part Number

Part Description

Package

Type (Surface mount, Thru-hole or Hybrid)

BOM for Turn-key and Partial Turn-key orders may include following information:

Line#

Quantity Per Part Number

Reference Designator

Part Number

Part Description

Package

Type (Surface mount, Thru-hole or Hybrid)

Manufacturers Name

Manufacturers Part Number

Distributors Part Number

Gerber Files

The same Gerber files in the format of “RS-274X / ODB++” that you send to us for your PCB fabrication will be required to assemble your boards. As a minimum request, the PCB assembler needs the files of three layers: Silkscreen, Copper (Track), and Solder Paste.


So please make sure that all these files have been included and reviewed on your side. Of course, we will also review your files before assembly starts to make sure all the information is complete and accurate for assemblies.

Centroid File

Centroid is the special file for assembly used for quickly programming the assembly machines. This is also known as aka Insertion, Pick-N-Place, or XY Data. Some of the CAD tools will automatically generate this file and some not, but you may need to modify the file and then generate the Centroid file.


The Centroid file describes the position and orientation of all the surface mount parts, which includes the reference designator, X and Y position, rotation and side of Board (Top or Bottom). Only surface mounting parts are listed in the Centroid.

Others

In order for us to properly assemble your printed circuits boards, we strongly recommend you send all other documents or information related to the boards to us, which may include your assembly drawings, special assembly instructions, and even images or photos of your work. These information helps us better understand your assembly needs, correcting some ambiguous or even mistaken placements, and ends up with an excellent job. Send them to us, though normally not required by assemblers.

Have Questions?

If you have any questions or need any further information, please feel free to contact your dedicated customer service.
