Printed Circuit Board (PCB) Prototype
PCB prototyping used to the nightmares of many electronics professionals. AlteraFlex now terminates the nightmares!
We can get your first-try boards in 24 hours!
Printed Circuit Board Prototype
After placing your order, our engineer will audit your Gerber files to make sure it complies with our technical spec. Once the files pass the audit, you can call us for payment. Also, our engineer will check again and optimize the files to make production.
The prototyping stage is the most critical period for engineers, students, and hobbyists. AlteraFlex has been in business since 2015 and has more than 17 years of manufacturing PCB experience.
Choosing AlteraFlex can not only shorten the manufacturing time of the PCB but also reduces the cost and get high-quality boards.
Check AlteraFlex PCB manufacturing capabilities in the following table:
| Feature | Capability |
|---|---|
| Min. Line Width | 0.076mm/3mil |
| Min. Hole Size | 0.15mm+-1mm |
| Min. Line Spacing | 0.076mm/3mil |
| Copper Thickness | 1oz---13oz |
| Base Material | Aluminum, FR4, Flex, Flex-rigid, HDI, Rogers, etc. |
| Board Thickness | 0.2,0.4, 0.6,0.8,1.0,1.2,1.6,2.0,2.4 mm |
| Surface Finishing | HASL with lead HASL, Lead-free, Immersion gold, OSP, Hard Gold |
| Finsih Cooper | 1-13oz |
| Solder Mask | Green, Red, Yellow, Blue, White, Black, Purple, Matte Black, Matte green |
| Silkscreen | White, Black |
| Testing | Fly Probe Testing (Free) and A.O.I. testing |
| Build time | 24 hours |
| Lead time | 2-3 days |
Have Questions?
If you have any questions or need any further information, please feel free to contact your dedicated customer service.
