Layer definition = unique labeling of each layer leads us how to make your board.

Layer orientation = labeling to avoid mirrored layers.

CONTACT US
Circuit Card Assembly

To produce your PCB correctly, it must have a label (name) for each layer.

Even when your data uniquely defines which layer the top or bottom is, the layer orientation for the Design Rule should be followed. Many Layout programs permit mirrored data output, so confusion may cause.

View from top side of the design file, we need all top and inner layers in normal vision as the real board, but for all bottom layers, mirrored vision is requested.
